The TH15-1 EEBD is an escape breathing apparatus which provides a constant supply of air for rapid escape from hazardous industrial and marine environments. The EEBD is available in durations of 15 minutes.
This escape breathing apparatus consists of a cylinder with a pressure reducing cylinder, air supply hose, hood and carrying bag. The TH15-1 EEBD is activated upon opening the bag.
The cylinder can be recharged by an air compresser. The seamless hood has a flexible neck seal to offer an effective gas tight function, easy to don and also comfortable to wear.
The EEBD TH15-1 is complying with the requirements in the following Regulations/Standards: Regulation (EU) 2020/1170, item No. MED/3.41. SOLAS 74 as amended, Regulation II-2/13, FSS Code 3 and IMO MSC/Circ. 849. MED approved by RINA.
Standards
ISO 23269-1:2008
EN 1146:2005
Approval
Directive 2014/90/EU on marine equipment (MED) by RINA.
2014/68/EU/PED (cylinder)
Materials
Hood: Fire retardant PVC, fluorescent green
Inner mask: silicon rubber
Visor: Fire retardant and surface anti fog treated PVC
Neck seal: silicone rubber
Air supplying hose: Wire reinforced PVC
Carrying bag: PVC coated polyester fabric
Bag Strap: fire retardant polyester webbing
Valve and regulator - brass and stainless steel
Structure
This escape breathing apparatus consists of a cylinder with a pressure reducing cylinder, air supply hose, hood and carrying bag.
EEBD is a compressed air emergency escape breathing device designed to offer respiratory protection. It is contained in a bag for carrying which, when opened, automatically triggers the supply of breathable air from the cylinder. Overpressure maintained inside the hood eliminates any risk of inhaling toxic gases. Placed in strategic locations, EEBD provides exceptional breathing protection for emergency escape from those areas where hazardous conditions may suddenly occur.
a)Cylinder Volume: 3.0L
b)Charging pressure: 210bar (+,-10bar)
c)Duration time: >=15 min
d)Alarm time: >=1 min
e)Amount of Air release: >=630L
f)Whole set weight (With gas): Not more than 7.5kg
g)Certificate：MED (RINA) / CE / CCS / RS
a)Safety green high visible color
b)Simple donning, rapid activated upon carrying bag is opened
c)Low maintenance required
d)Wide vision hood fits all persons
e)Stable air-flow for 15 minutes
f)Plastic Wall mounting boxes are available for easy and safe storage.
g)Easy visual inspection on the pressure gauge through the transparent window on the carrying bag.
a)EEBD Spare Hood with air hose
b)EEBD Cylinder Valve
c)EEBD carrying Bag
d)EEBD pressure Gauge
MED APPROVED BY RINA, MEET SOLAS REQUIREMENT
Normally delivered with empty cylinders
May also deliver with fully charged cylinder under UN 1002, Class 2.2 as DG cargo in FCL.
Normally delivered with empty cylinders
May also deliver with fully charged cylinder under UN 1002, Class 2.2 as DG cargo in FCL.
Q: What is Emergency Escape Self Contained Breathing Device (EEBD)?
A: EEBD is a compressed air emergency escape breathing device designed to offer respiratory protection. It is contained in a bag for carrying which, when opened, automatically triggers the supply of breathable air from the cylinder.
Q: Are you an EEBD maker or dealer?
A: We have our own production factory Kunshan EMF Marine Production Co., Ltd. But we don't produce EEBDs. EMF Marine is the dealer of a few famous brands EEBD made in China, such as Fangzhan, Huayan, Dongtai Jianghai,Dongtai City Dongfang Marine, Rongsheng etc. All EEBDs we supply are chosen to be stable in quality, MED approved and are fully tested before and after final assembling.
Q: Are your EEBD competitive in term of price?
A: Yes. The EEBD we supplied are competitive in price compare to the EEBD on the same quality level on the market. We have long term good cooperation with our business partners who offer us decent discount so to make sure our price competitive even in completion with other EEBD makers from China.
Q: What certifications can you provide?
A: We offer MED B and D approval by DNV or RINA as per MED requirement.
Q: Which brand of EEBD do you recommend?
A: This can only be talked on email. We do have our experience on different brands of SCBAs made in China. We may recommend you the SCBA according to your specific requirement.
For example, easy operate, ergonomically designed and light weight, sturdy, reliable design, easy maintenance.
Q: How do you control the quality of EEBD?
A: Our cooperated business partner strictly complies with the ISO9001 process to control the quality and provide quality warranty for 12 months.
Q: How long is the delivery time for EEBD?
A: Normally 3 to 4 weeks lead time. Lead time can be shorter in urgent cases.
Q: How to make sure that EEBD is not damaged due to the long shipping cycle?
A: Our EEBD is packed in specially designed foam, ensuring the EEBD a safe transportation.
Q: Are there any limitations on EEBD?
A: The EEBD is designed to for escaping purpose only, not for entering hazardous environment or firefighting.
Q: What are security considerations when using EEBD?
A: The working during of the EEBD is 15 minutes as maximum. When the whistle alarms, the rest air can only be enough for a few minutes, the user must evacuate from the toxic environment and enter the safety area as soon as possible, otherwise, it will cause life risk.
Q: What are your strengths over EEBD?
A: Compliance with the latest European Maritime Equipment (MED) and international regulation and standards (SOLAS, Safety of Life At Sea).
Unique design of all key components, like integrated cylinder valve with pressure reducer, fire retardant hood, comfortable inner mask and orange warning color carrying bag.
Q: What are the product advantages of your EEBD?
A: Very simple to use and can be donned in less than one minute.
The air flow is activated automatically when the carrying bag is open.
The cylinder gauge can be easily viewed from the outside of the carrying bag, makes it easier for daily inspection and also monitoring the rest air during escaping.
Q: Are your EEBD competitive is price?
A: We aim to deliver quality goods, but our EEBD is competitive in price compare to the EEBDs in the same quality level.
Q: How do you control the quality of EEBD? What should I do if there is a problem with EEBD quality?
A: Our cooperated business partners strictly comply with the ISO9001:2015 process to control the quality.
Quality warranty period is 12 months since production date.
Q: What is the ordering process and how do I order EEBD?
A: You can send your order to our email: sales@emfcn.com, our sales person will handle your order shortly.
Q: What are the payment methods for my order?
A: Normally T/T by shipment. We offered credit for some long term cooperation customers.
Q: Do you have a local agent of EEBD in our country?
A: In some area, we have. We able to check if you advise your country name.
Q: How long is the delivery time for EEBD?
A: Normally 3 to 4 weeks for production. For urgent orders, we may handle specially to reduce the lead time
Q: How can I ensure that EEBD is not damaged due to the long shipping cycle?
A: Our EEBD is packed in specially designed solid protection foams, ensuring the EEBDs a safe long journey to overseas customers.
